​​Industrial Shale Shaker 2.2 KW PT 5K G Force Shale Shaker 2997MM

​​Industrial Shale Shaker 2.2 KW PT 5K G Force Shale Shaker 2997MM

Brand Name: XBSY
Model Number: ZS
MOQ: 1
Price: Price Negotiable
Payment Terms: TT
Supply Ability: 1000
Detail Information
Place of Origin:
Sichuan,China
Certification:
USE 18000,USE14000,EAC,CE,ISO9000
Document:
Vibration Track:
Translational Elliptical / Variable Elliptical
Motor Power:
2 * 2.2 KW + 1.2 KW
Screen Size:
1165 * 585 * 40 Mm
Screen Number:
5
Total Screen Area:
3.40㎡
Vibration Amplitude:
> 5.2 Mm
Vibration Intensity:
> 6.5 G
Tilt Adjustment Range:
-1° ~ +4°
Power Supply:
AC 380V / 50HZ
Explosion-proof Grade:
E* D II B T4 Gb
Weight:
2260 Kg
Dimensions (L * W * H):
2997 * 1728 * 1650 Mm
Packaging Details:
Ply Wood Box,iron box
Highlight:

Industrial Shale Shaker 2.2 kW

,

Shale Shaker PT 5K

,

g force shale shaker 2997MM

Product Description
Industrial ZS-Z / PT-5K Shale Shakers Explosion-Proof Motors & Maintenance-Free Design
Maximize productivity with ZS-Z/PT-5K and ZS-S-5K models, offering 5 screens and 3.4㎡ total filtration area. The all-round anti-splash design reduces mud wastage by 40%, and maintenance-free frame screens cut operational costs. Powered by dual 2.2kW motors (AC 380V/50Hz), these shakers deliver >5.2mm amplitude for consistent performance. Integrated triple-base or mud-box options simplify installation.
​​Industrial Shale Shaker 2.2 KW  PT 5K G Force Shale Shaker 2997MM 0
Key Features
  • Two motion tracks - Adaptable to different working condition requirements
  • High-quality motor - Designed for harsh outdoor explosion-proof environments
  • Frame screen & adjustable deck angle - Easy screen replacement with maintenance-free operation
  • Patented fast pressing screen - Simplifies screen replacement process
  • Anti-loosening thread technology - Ensures reliable connections in vibrating conditions
  • All-round anti-splash design - Significantly reduces mud splash during operation
  • Heavy-duty anti-corrosion coating - Extends equipment lifespan
  • Integrated design options - Available with double or triple integral base and integral mud box
Technical Specifications
Model ZS-Z / PT-5K
Vibration Track Translational Elliptical / Variable Elliptical
Motor Power 2 * 2.2 kW + 1.2 kW
Screen Size 1165 * 585 * 40 mm
Screen Number 5
Total Screen Area 3.40㎡
Vibration Amplitude > 5.2 mm
Vibration Intensity > 6.5 g
Tilt Adjustment Range -1° ~ +4°
Power Supply AC 380V / 50HZ
Explosion-proof Grade E* d II B T4 Gb
Weight 2260 kg
Dimensions (L * W * H) 2997 * 1728 * 1650 mm
