| Brand Name: | XBSY |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
The LW450×1000-N power frequency centrifuge delivers reliable 2–5µm fine solids removal in conventional drilling operations. With three drum speed options (1,800/2,000/2,200 RPM) adjustable via pulley configuration, it generates centrifugal forces up to 1,219 Fr to efficiently separate harmful 6–10µm solid phases. The 37kW main motor supports 60 m³/h throughput while minimizing barite loss. Compact dimensions (2750×1580×1780 mm) suit mobile rigs. Weight: 3,200 kg.Duplex stainless steel drum (450 mm diameter) resists abrasion from silica-rich formations. Tungsten carbide tiles protect conveyor blades, extending wear life to 8,000 hours. Vibration isolators ensure stability on uneven terrain, while the compact footprint integrates into existing mud tanks.
Features
Constant Drum Speed - Can be changed by changing the drive pulley.
Easy to Operate and Maintain- Can be matched with different drum speeds and processing capacities according to the size of the drilling rig and actual demand.
Cost-saving - The centrifuge of choice for conventional drilling mud treatment.
| Model | LW450 × 1000-N |
| Drive Type | Power Frequency |
| Drum Inner Diameter (mm) | 450 |
| Drum Working Length (mm) | 1000 |
| Maximum Drum Speed (r/min) | 2500 |
| Drum Working Speed (r/min) | 1800 / 2000 / 2200 |
| Fr | 815 / 1007 / 1219 |
| Pusher Differential Speed (r/min) | 25 / 29 / 33 |
| Max. Capacity (m3/h) (Clearwater) | 60 |
| Rated Power (kW) (Main Motor) | 30 / 37 kW |
| Rated Speed (r/min) (Main Motor) | 1470 / 1480 r / min |
| Rated Power (kW) (Auxiliary Motor) | 7.5 kW |
| Rated Speed (r/min) (Auxiliary Motor) | 970 r/min |
| Feeding Pump Model | Screw Pumps or Centrifugal Pumps |
| L * W * H (mm) | 2750 × 1580 × 1780 |
| Weight (kg) | 3200 |
