| Brand Name: | XBSY |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
The LW355×1435B VFD centrifuge utilizes PLC programming for stepless drum speed adjustment (0–3,400 RPM), enabling precise adaptation to variable mud densities in complex drilling conditions. Operators monitor drum speed, torque, and bearing temperature in real time via the explosion-proof touchscreen, ensuring optimal separation efficiency while reducing manual intervention. Ideal for upgrading legacy solids control systems or integrating into automated drilling rigs. Weight: 4,000 kg; dimensions: 3400×1550×1780 mm.Track critical parameters—differential speed (≤50 RPM), motor current, and machine vibration—on the color touchscreen interface. Automated alerts trigger for abnormal conditions (e.g., bearing temperature spikes), allowing proactive maintenance in remote shale gas or high-pressure wells. The 37kW main motor (1470 RPM) supports 40 m³/h throughput while minimizing unplanned downtime.
Features
PLC Programming Control - Drum speed can be steplessly adjusted within the design range.
Equipped with color explosion-proof touch screen, real-time view of speed, current, torque, bearing temperature, whole machine vibration, differential speed, etc.
Intelligent control, easy operation, large processing capacity, good effect and low failure rate.
| Model | LW355 × 1435B |
| Drive Type | VFD Intelligent Variable Frequency |
| Drum Inner Diameter (mm) | 355 |
| Drum Working Length(mm) | 1435 |
| Maximum Drum Speed (r/min) | 4000 |
| Drum Working Speed (r/min) | ≤ 3400 |
| Fr | ≤ 2298 |
| Pusher Differential Speed (r/min) | ≤50 |
| Max. Capacity (m³/h) | 40 |
| Rated Power (kW) (Main Motor) | 37kW |
| Rated Speed (r/min) (Auxiliary Motor) | 1470 r / min |
| Feeding Pump Model | Screw Pumps or Centrifugal Pumps |
| L * W * H (mm) | 3400 × 1550 × 1780 |
| Weight(Kg) | 4000 |
