| Brand Name: | XBSY |
| Model Number: | QJ / 300×2 - 125×12-K QJ / 250×3 - 100×16-K QJ / 300×2 - 125×12 QJ / 250×3 - 100×20-A |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
Durability in Extreme Environments
Heavy-duty epoxy coating withstands abrasive slurries and saline corrosion. Stainless-steel fasteners and carbon-steel reinforcement ensure 3050kg structural stability during high-G vibration, ideal for offshore platforms or desert drilling sites.
Energy-Efficient Operation
AC 380V/50Hz motors consume 15% less power than conventional units. The optimized cyclone geometry reduces pressure drop, while maintenance-free bearings cut lubrication costs by 50% over rival models.
| Model | QJ / 250×3 - 100×20-A |
| Vibration track | Liner |
| Motor Power | 2 × 1.94 kW |
| Screen Size | 1150 × 697 mm |
| Screen Number | 3 |
| Vibration Amplitude | > 5.2 mm |
| Desanding Cyclone Specifications | 250 |
| Desanding Cyclone Number | 3 |
| Desilting Cyclone Specifications | 100 |
| Desilting Cyclone Number | 20 |
| Pressure | 0.15 ~ 0.3 MPa |
| Power | AC 380V / 50HZ |
| Explosion-proof Grade | Ex d II B T4 Gb |
| Weight | 3200 kg |
| L × W × H (mm) | 3240 × 2147 × 2655 |
| Note | The models in the table are only examples, cyclone specifications and quantities can be configured according to user requirements. |
