| Brand Name: | XBSY |
| Model Number: | QJ / 300×2 - 125×12-K QJ / 250×3 - 100×16-K QJ / 300×2 - 125×12 QJ / 250×3 - 100×20-A |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
Vibration & Splash Control
Linear vibration at >5.2mm amplitude ensures consistent solids conveyance, paired with all-round anti-splash barriers that cut mud spillage by 90%. The frame screen structure enhances structural integrity under cyclic loads, requiring zero reinforcement during transport or operation.
Customizable Cyclone Configuration
Adapt to diverse drilling conditions with configurable cyclone specs. The 300mm desanders (×2 units) remove 40–70μm particles, while 125mm desilters (×12 units) target 15–40μm fines. Overflow purity meets API RP 13C standards, reclaiming 95% of reusable drilling fluid.
High-quality motor - adapt to the harsh environment of outdoor explosion-proof use.
Frame screen & adjustable deck angle - easy and reliable to replace, maintenance-free.
Compact arrangement and easy operation.
Patented fast pressing screen - easy to replace the screen.
Anti-loosening thread technology - reliable connections in vibrating environments.
All-round anti-splash – significantly reduces mud splash.
Heavy-duty anti-corrosion coating - ensures the long-term use of the equipment.
| Model | QJ / 300×2 - 125×12 |
| Vibration track | Liner |
| Motor Power | 2 × 1.94 kW |
| Screen Size | 1053 × 697 mm |
| Screen Number | 3 |
| Vibration Amplitude | > 5.2 mm |
| Desanding Cyclone Specifications | 300 |
| Desanding Cyclone Number | 2 |
| Desilting Cyclone Specifications | 125 |
| Desilting Cyclone Number | 12 |
| Pressure | 0.15 ~ 0.3 MPa |
| Power | AC 380V / 50HZ |
| Explosion-proof Grade | Ex d II B T4 Gb |
| Weight | 3050 kg |
| L × W × H (mm) | 3170 × 1960 × 2684 |
| Note | The models in the table are only examples, cyclone specifications and quantities can be configured according to user requirements. |
