| Brand Name: | XBSY |
| Model Number: | QJ / 300×2 - 125×12-K QJ / 250×3 - 100×16-K QJ / 300×2 - 125×12 QJ / 250×3 - 100×20-A |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
Patented fast-pressing screen technology enables tool-free screen replacement in minutes, reducing downtime. Anti-loosening thread connections prevent vibration-induced failures, while the adjustable deck angle optimizes screening efficiency for varying mud viscosities without manual recalibration.Vibration & Splash ControlLinear vibration at >5.2mm amplitude ensures consistent solids conveyance, paired with all-round anti-splash barriers that cut mud spillage by 90%. The frame screen structure enhances structural integrity under cyclic loads, requiring zero reinforcement during transport or operation.
| Model | QJ / 250×3 - 100×16-K |
| Vibration track | Liner |
| Motor Power | 2 × 1.94 kW |
| Screen Size | 1165 × 585 × 40 mm |
| Screen Number | 4 |
| Vibration Amplitude | > 5.2 mm |
| Desanding Cyclone Specifications | 250 |
| Desanding Cyclone Number | 3 |
| Desilting Cyclone Specifications | 100 |
| Desilting Cyclone Number | 16 |
| Pressure | 0.15 ~ 0.3 MPa |
| Power | AC 380V / 50HZ |
| Explosion-proof Grade | Ex d II B T4 Gb |
| Weight | 3200 kg |
| L × W × H (mm) | 2960 × 2300 × 2600 |
| Note | The models in the table are only examples, cyclone specifications and quantities can be configured according to user requirements. |
