| Brand Name: | XBSY |
| Model Number: | ZS |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 1000 |
| Model | ZS / PT-5K (F) |
|---|---|
| Vibration Track | Translational Elliptical |
| Motor Power | 2 × 2.2 kW |
| Screen Size | 1165 × 585 × 40 mm |
| Screen Number | 5 |
| Total Screen Area | 3.40 ㎡ |
| Vibration Amplitude | > 5 mm |
| Vibration Intensity | > 6.5 g |
| Tilt Adjustment Range | -1° ~ +4° |
| Power Supply | AC 380V / 50HZ |
| Explosion-proof Grade | E× d II B T4 Gb |
| Weight | 2980 kg |
| Dimensions (L × W × H) | 3080 × 1732 × 2204 mm |
| G-Force | 6.3 G |
|---|---|
| Vibration Strength | <8.5G |
| Usage | Separate Solids From Mud |
| Screen Type | Hookstrip Shaker Screen |
| Deck Angle | 0-5 degrees |
| Material | 304 |
| Amplitude | 7mm |
| Material Of Shaker | Hard alloy |
| Adjustment Angle | -3~3° |
| Vibration Motion | Balanced Elliptical Motion |
| Deck Angle Range | -1° - 5° |
