| Brand Name: | XBSY |
| Model Number: | LW，LWS |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | TT |
| Supply Ability: | 500 |
The involute planetary gear system maintains stable torque transmission under variable loads (e.g., palm sludge with 50% solids). SKF bearings support 20,000+ hours of operation, while adjustable differential speed (5–50 RPM) optimizes solids dryness to ≤70% moisture—critical for efficient dewatering.Duplex stainless steel (AISI 316L) drum resists H₂S corrosion in palm oil effluent. Tungsten carbide tiles protect conveyor scrolls from silica abrasion, extending wear life to 8,000 hours. Vibration dampeners ensure stability on uneven factory floors
Features
CIP fully automatic cleaning system.
High torque involute planetary gear differential.
High dryness screw conveyor and drum structure.
Clever, unique and diverse three-phase separation structure.
Patented light-phase liquid layer adjustment technology allows adjustment work to be completed without disassembling the machine.
|
Model |
Speed(Rpm) | G-Force | Capacity(m³/h) | Dimension(mm) |
| LWY520 | 3200 | 2982 | 10 ~ 15 | 5050 × 1285 × 1550 |
